Complies with asse 1019 2004 upc iampo listed.
Watts roof hydrant.
Series hy 900 non freeze roof hydrant has an epoxy coated cast iron head with lift handle and lock option galvanized casing bronze internal working parts and valve housing and integral epoxy coated cast iron roof mounting plate with clamping collar and 1 8 in.
Epdm boot covers well seal and top of hydrant support.
The hydrant is supported by a heavy duty cast iron ms mounting system.
4 bolts draw tight against the roof decking and the hydrant support.
The hydrant is installed through the roof and plumbed to the non freezing interior water source.
Roof hydrants are specified for.
All necessary mounting hardware for proper installation on a commercial roof is supplied including a 2 degree shim for pitch adjustment.
Object moved this document may be found here.
3 clamp screws tighten against the hydrant pipe to secure the hydrant s vertical position through the roof.
Watts drainage hy 900 non freeze roof hydrant with epoxy coated cast iron head with lift handle and lock option galvanized casing bronze internal working parts and valve housing integral epoxy coated cast iron roof mounting plate with clamping collar and 1 8 npt drain port.
Our exclusive dual functional structural deck flange and combination roof drains streamline specifications saving installation time and labor.
Commercial hydrants over built for commercial specification watts hydrants are engineered for durability in high use applications.
Series hy 420 non freeze key operated wall hydrant with chrome plated face integral vacuum breaker 3 4 in 19mm hose connection 3 4 in 19mm female x 1 in 25mm male pipe connection all bronze head seat casting and internal working parts bronze wall casing and loose key.
Well seal seals tight between the hydrant support and hydrant pipe.
Watts roof drains provide flexible solutions for specifiers and installers in any commercial roof application.
